Universal Fiber Optic Tools Kits FTTH Fusion Splicing Kits Optic Power Meter + Visual Fault Locator
• Optical Power Meter: Wavelength: 800-1700nm; Measurement Range: -70+3dBm / -50~+26dBm; Resolution (dB): 0.01.
• Fiber Optic Cleaning wipes: Ergonomic, comfortable design with single action cleaning.
• Fiber Cleaver: Cleaved Angel <0.5 degress; 48,000 times Long blade life; Universal fiber holder for 250μm, 900μm, 3.0mm fiber cabl3
• Visual Fault Locator: 1mW
• Others: High Quality Carry bag; Fusion Splice Sleeves; Allen Wrench and so on.
Product introduce：
ORIETEK TFS series optical fiber splicing toolkit is suitable for fiber fusion, fiber loss testing, fiber cleaning, fiber break point detection and other fields.
It contains all necessary tools such as fiber cutting, breakpoint detection, cleaning and loss testing, etc. In addition, it is rainproof, rainproof, easy to carry, large capacity and small volume, which can adapt to all indoor and outdoor working environments.
Product features:
• Anti - rain, anti - fall, easy to carry
• Complete configuration
• Suitable for fiber fusion, loss testing, cleaning, breakpoint detection and other fields.
• Special tool partition design
Product configurations:
|
Product name |
Usage |
TFS-40N |
TFS-40E |
TFS-40D |
|
Fiber Cleaver |
Cut fiber |
0 |
1 |
1 |
|
Assembled Screwdriver |
Elastic tool |
8-in-1 |
8-in-1 |
8-in-1 |
|
Wire Cable Stripper |
Stripping optical cable, optical fiber sheath |
1 |
1 |
1 |
|
Fusion Splice Sleeves |
Protect the fiber |
100 |
100 |
100 |
|
Electrical Tape |
Wire & cable protection |
1 |
1 |
1 |
|
Mini Saw |
Cut Wire & cable |
1 |
1 |
1 |
|
Optic Fiber Stripper |
Peel off the optical fiber coating |
1 |
1 |
1 |
|
Cable Cutter |
Strip the sheath of wire & cable |
1 |
1 |
1 |
|
Visual Fault Locator |
Fiber break point detection |
0 |
0 |
1 |
|
Alcohol Bottle |
Storage of alcohol |
1 |
1 |
1 |
|
Fiber Optic Cleaning Platform |
Optic fiber and connector cleaning |
1 |
1 |
1 |
|
Knife |
cutting |
1 |
1 |
1 |
|
Optical Power Meter |
Test fiber loss |
0 |
0 |
1 |
|
Scissors |
Cut fiber |
1 |
1 |
1 |
|
Long Nose Plier |
Optical fiber & fiber cable sleeve stripping |
1 |
1 |
1 |
|
Combination Plier |
Optical fiber & fiber cable sleeve stripping |
1 |
1 |
1 |
|
Diagonal Cutting Plier |
Optical fiber & fiber cable sleeve stripping |
1 |
1 |
1 |
|
Round Cable Slitter |
Cut wire&cable |
1 |
1 |
1 |
|
Wrench |
Install & remove tools |
1 |
1 |
1 |
|
Hammer |
Hitting tool |
1 |
1 |
1 |
|
Cleaning air ball |
Dust removal tool |
1 |
1 |
1 |
|
Neon-electroscope |
Current detection |
1 |
1 |
1 |
|
Mark Pen |
Mark and write |
1 |
1 |
1 |
|
Tape Measure |
Measurement |
1 |
1 |
1 |
|
Allen Wrench |
Install & remove tools |
9-in-1 |
9-in-1 |
9-in-1 |
|
Coxial Cable Stripper |
Strip fiber optic hose |
1 |
1 |
1 |
|
FTTH Drop Cable Stripper |
Peeling cable |
1 |
1 |
1 |
|
Carry bag |
1 |
1 |
1 |
